Description

Features

• The ESC uses a special process, coupled with an innovative waterproof design, to increase waterproofing and dust-proofing performance in different climates. It is easy to deal with the harsh conditions containing sediment, ice and snow, water accumulation.
• Built-in ultra-powerful switch mode BEC with a continuous current of 8A, an instant 25A, and support for 6V/7.4V/8.4V switching, supporting a wide range of powerful and high-voltage servos.
• Supports turbo timing setting, the timing response is remarkable when used with the matching motor(such as EZRUN 56118SD G2 Sensored brushless motor).
• Multiple protection functions: battery low voltage protection, ESC and motor overheat protection, signal loss protection, current protection.
• Supports LED program card, LCD G2 program box, OTA programmer (Note: optional) to set the parameters of the ESC.
• Data logging function to view various running data on the HW LINK app using the OTA Bluetooth module.
• Supports the firmware upgrade of the ESC (The multi-function LCD G2 program box or OTA Programmer is needed to purchase), you can enjoy the latest functions

Specifications

Cont./Peak Current: 250A/1600A
Input Voltage: 6-12S Lipo
BEC Output: 6V/7.4V/8.4V adjustable, continuous current 8A (Switch-mode)

Wires & Connectors
Input Wires: Black-8AWG-200MMmm*1/Red-8AWG-200MMmm*1
Input Connectors: 8.0mm Bullet Connectors (Female)

Size & Weight
Size: 94.5*59.4*50.9mm
Weight: 428.5g (Included input wires)

Applications
Motors: Sensored / Sensorless Brushless Motor
Vehicles: 1/5th Buggy, Truck
KV Rating/T Count: 56118 size motor
