Description
Specifications
Max. Cont. Current (A): 185 A
Motor Limit: 4S LiPo = 3000 Kv (40XX series of motors) 6S LiPo = 2400 Kv (40XX series of motors)
Input Voltage (V) min. - max.: 11.1-22.2
Max. Current (A): 950 A
Length (mm): 60.0mm
Nr of Li-xx Cells: 3-6S
Width (mm): 48.0mm
Nr of Ni-xx Cells: 9-18 Cell NiMH
Motor Type: Sensored / Sensorless Brushless Motor (only in sensorless mode)
Height (mm): 36.5mm
BEC Voltage (V): 6-7.4 V programmable
BEC Current (A): 6 A
Programmable: Yes
Programming Card: Hobbywing LED (optional)
Throttle Mode: Forward / Reverse programmable Reverse lockout
Drag Brake: 0-16% programmable
Battery Mode: NiMH/LiPo programmable
Lipo Cut-Off: programmable
Thermal Protection Temperature: 105?C / 125?C programmable
Water Protection: Yes
Element Protection: Yes
Cooling Fan: 30x30x10mm
Connector (Motor): 6.5 mm female
Connector (Battery): XT90-connector
Battery Wire Size: 10 AWG
Car Type Use: 1/8th scale
Product information
- Brand
- Corally
- Product type
- Car Speed Controllers
- SKU / part number
- C-54011
- Availability
- In stock
- Regular price
- £139.99
- Sale price
- £125.99
- Regular price
- £139.99
- Sale price
- £125.99
Delivery information
Delivery information
Delivery options and costs are shown at checkout. Contact us before ordering if you need an item urgently.
Returns & exchanges
Returns & exchanges
Changed your mind or ordered the wrong part? Contact our team and we will help with the next step.
Need compatibility help?
Need compatibility help?
Send us your model and part number before ordering if you are unsure. We would rather help you get the correct item first time.
Description
Specifications
Max. Cont. Current (A): 185 A
Motor Limit: 4S LiPo = 3000 Kv (40XX series of motors) 6S LiPo = 2400 Kv (40XX series of motors)
Input Voltage (V) min. - max.: 11.1-22.2
Max. Current (A): 950 A
Length (mm): 60.0mm
Nr of Li-xx Cells: 3-6S
Width (mm): 48.0mm
Nr of Ni-xx Cells: 9-18 Cell NiMH
Motor Type: Sensored / Sensorless Brushless Motor (only in sensorless mode)
Height (mm): 36.5mm
BEC Voltage (V): 6-7.4 V programmable
BEC Current (A): 6 A
Programmable: Yes
Programming Card: Hobbywing LED (optional)
Throttle Mode: Forward / Reverse programmable Reverse lockout
Drag Brake: 0-16% programmable
Battery Mode: NiMH/LiPo programmable
Lipo Cut-Off: programmable
Thermal Protection Temperature: 105?C / 125?C programmable
Water Protection: Yes
Element Protection: Yes
Cooling Fan: 30x30x10mm
Connector (Motor): 6.5 mm female
Connector (Battery): XT90-connector
Battery Wire Size: 10 AWG
Car Type Use: 1/8th scale
Product information
- Brand
- Corally
- Product type
- Car Speed Controllers
- SKU / part number
- C-54011
- Availability
- In stock
-
